Technical data:
- Brand: Nivel System
- Operating temperature range:
- -10°C to +50°C
- Leveling accuracy:
- ±2.0mm/10m
- Self-leveling range:
- ±3.5°
- Plane tilt: yes
Instead of zł1,695.99
The lowest price of the product zł1,463.69 in day 15.03.2025
Lowest price in the last 30 days
W ratach już od:
29.2738 złmiesiecznie
Oblicz ratę
Wybierz bank aby obliczyć ratę
×Application
- finishing works - vertical, horizontal, bevel
- laying tiles, terracotta
- works with cardboard-plaster
- construction works - wooden, steel, concrete
- leveling - inside and outside
The set includes
- cross laser CL1 - 1 pc.
- batteries - 1 kpl.
- carrying case - 1 pc.
- tripod SJJ-M1 EX - 1 pc.
Nivel System CL1 construction laser
Cross laser Nivel System CL 1 is designed to determine the horizontal and vertical plane, as well as both simultaneously in the form of a cross with arms intersecting at right angles. The equipment, thanks to its very clear reference lines, can be used both indoors and outdoors. The pulse function allows you to use the laser sensor and work with the instrument at longer distances, even outdoors. Included in the package with the laser are a practical adapter, which allows you to conveniently position the laser.
Nivel System SJJ-M1 construction laser
A tripod is one of those surveying accessories that 90% of surveying jobs require. Choosing the right model of "tripod" for the type of tasks to be performed is half of professional success. For surveying with a total station, you should use a wooden tripod, which is characterized by high rigidity and provides stability to the instrument. In turn, for work with an optical or laser leveler, it is worth using a lightweight and easy to transport aluminum tripod. There are tripods that help to perform all measuring tasks - surveying and general construction.
Maximum tripod height: approx. 1.82 m
Minimum tripod height: approx. 0.62 m
Construction laser Nivel System CL1
Cross laser Nivel System CL 1 is designed to determine the horizontal and vertical plane, as well as both simultaneously in the form of a cross with arms intersecting at right angles. The equipment, thanks to its very clear reference lines, can be used both indoors and outdoors. The pulse function allows you to use the laser sensor and work with the instrument at longer distances, even outdoors. Included in the package with the laser are a practical adapter, which allows you to conveniently position the laser.
Function
Nivel System CL1 cross laser is designed to determine the horizontal and vertical plane, as well as both simultaneously in the form of a cross with arms intersecting at right angles. The equipment, thanks to its very clear reference lines, can be used both indoors and outdoors. The pulse function allows you to use the laser sensor and work with the instrument at longer distances, even outdoors. Included in the package with the laser are a practical adapter, which allows you to conveniently position the laser.
Register the Product and get 24 Months Warranty
Nivel System CL1 construction laser
Warranty of authorized service
Warranty in Poland for a period of 12 months (with the possibility of extension to 24 months at https://www.nivelsystem.com/pl/przedluzenie-gwarancji). The basis for respecting the terms of the warranty is to have a proof of purchase containing the equipment's serial number. Customers are assured of support in case of any problems with the equipment both during and after the warranty period.
- Buy from Toolsa
- Register Product
- Extended Warranty
See CL1 in action
Nivel System CL1 construction laser
EASYAND FAST MEASUREMENTS Laser is easy and fast to use, Allows one person to mark horizontal and vertical reference lines on the wall.
RELIABLEON CONSTRUCTION Nivel System CL1 cross laser is an instrument that replaces the spirit level in most construction work. One person can mark out horizontal and vertical reference lines on the wall, which are used to hang furniture at the same height, place electrical sockets and switches at the same level, align drywall construction vertically, and transfer points from floor to ceiling in a straight line.
UNIVERSAL APPLICATION The Nivel System CL1 is distinguished from similar instruments by its pulsed laser function, in which case it uses a laser sensor and works in open spaces where normally the beam is not visible. A laser adapter is included as standard for quickly suspending the laser on a wall (or structural component) with magnets and for quickly adjusting the level and direction of the laser beam. Built-in 1/4-inch and 5/8-inch threads are used for stable mounting of the instrument on a photographic tripod or on a traditional surveying tripod (without the need for additional adapters).
COMFORTABLEOPERATION The display of the vertical and horizontal beams makes it possible to determine right angles, which is useful in tiling work. An additional laser point allows you to transfer points horizontally without turning on the vertical beam (saves batteries). Electronic locking of the compensator makes it possible to tilt the instrument and use oblique lines.
Data sheet
Ciężar | 0.7kg |
---|---|
Wymiary | 150 x 65 x 160 mm |
Marka | Nivel system |
Zasilanie | Li-ion 7.4v (2600mah). 4×1.5v (aa) |
Zakres temperatur pracy | -10°c do +50°c |
Dokładność poziomowania | ±2.0mm/10m |
Zakres samopoziomowania | ±3.5° |
Pochylenie płaszczyzn | Tak |
Generowane płaszczyzny | 1 x poziomo (360°). 1 x pionowo (360°) |
Mocowanie na statyw | 1/4". 5/8" |
Zasięg pracy | 60 m (140 m z czujnikiem) – średnica |
Rodzaj wiązki lasera | Laser czerwony (635 nm). klasa 2 |
Klasa odporności | Ip54 |
Kolor lasera | Czerwony |
